Rods for BTS-150 rigs
Brief specifications
- Image
- NameAdapter Z-50V/NC 38 (3 1/2 IF) MX 221.00
- Internal threadlock thread Z-50
- External threadNC 38 (3 1/2 IF)
- Diameter, mm.140
- Length, mm.130
- Weight, kg.9,6
- PurposeAdapter from the URB rod to the P-160 pneumatic hammer
Adapter Z-50V/NC 38 (3 1/2 IF) MX 221.00
PART NUMBER: MH 221.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter Z-50V/72-10N MH 222.00
- Internal threadlock thread Z-50
- External threadtape thread 72-10
- Diameter, mm.98
- Length, mm.79
- Weight, kg.2,1
- PurposeAdapter from the URB rod to the P-110 and P-130 pneumatic hammers
Adapter Z-50V/72-10N MH 222.00
PART NUMBER: MH 222.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter Z-50N/52-M MH 230.00
- Internal threadlock thread Z-50
- External threadbayonet Ø52
- Diameter, mm.98
- Length, mm.79
- Weight, kg.2,1
- PurposeAdapter from the P-110-2.8 MP pneumatic hammer to a core drill
Adapter Z-50N/52-M MH 230.00
PART NUMBER: MH 230.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter Z-50N/62-M MH 232.00
- Internal threadlock thread Z-50
- External threadbayonet Ø62
- Diameter, mm.105
- Length, mm.235
- Weight, kg.5,9
- PurposeAdapter from the P-130-4.0 MP pneumatic hammer to a core drill
Adapter Z-50N/62-M MH 232.00
PART NUMBER: MH 232.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter Z-58x3B/Z-102 MH 223.00
- Internal threadlock thread Z-58x3
- External threadNC 38 (3 1/2 IF)
- Diameter, mm.140
- Length, mm.130
- Weight, kg.9,4
- PurposeAdapter from NKR rod to pneumatic hammer P-160
Adapter Z-58x3B/Z-102 MX 223.00
PART NUMBER: MH 223.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter Z-58x3B/72-10H MH 225.00
- Internal threadlock thread Z-58x3
- External threadtape thread 72-10
- Diameter, mm.98
- Length, mm.79
- Weight, kg.1,8
- PurposeAdapter from NKR rod to pneumatic hammers P-110 and P-130
Adapter Z-58x3B/72-10H MH 225.00
PART NUMBER: MH 225.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter Z-58x3B/SH41V MH 227.00
- Internal threadlock thread Z-58x3
- External threadhexagonal 41
- Diameter, mm.65
- Length, mm.391
- Weight, kg.7,0
- PurposeAdapter from the SBU machine's rotary head to the auger
Adapter Z-58x3B/SH41V MX 227.00
PART NUMBER: MH 227.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter Z-58x3H/56x12H MH 240.00
- Internal threadlock thread Z-58x3
- External threadtrapezoidal thread 56x12
- Diameter, mm.76
- Length, mm.340
- Weight, kg.7,4
- PurposeAdapter from the P-85 pneumatic hammer to the BP-76 rod
Adapter Z-58x3H/56x12H MH 240.00
PART NUMBER: MH 240.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter Z-58x3H/Z-50V MH 246.00
- Internal threadlock thread Z-58x3
- External threadlock thread Z-50
- Diameter, mm.78
- Length, mm.145
- Weight, kg.3
- PurposeAdapter from a P-85 pneumatic hammer to a NKR rod with a 3-50 thread
Adapter Z-58x3H/Z-50V MH 246.00
PART NUMBER: MH 246.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter 3 1/2 Reg / 3 1/2 Reg MH 226.00
- Internal thread3 1/2 Reg
- External thread3 1/2 Reg
- Diameter, mm.120
- Length, mm.267
- Weight, kg.12,7
- PurposeAdapter from the BTS machine rotator to the BTS rod
Adapter 3 1/2 Reg / 3 1/2 Reg MH 226.00
PART NUMBER: MH 226.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter Z-77V/12x10N MH 249.00
- Internal threadlock thread Sp. Z-77
- External threadtabe thread Z-88
- Diameter, mm.93
- Length, mm.146
- Weight, kg.3,6
- PurposeAdapter from the SBU-100GA-50 machine rotator to the SBU-89 rod
Adapter Z-77V/12x10N MH 249.00
PART NUMBER: MH 249.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter NC 38 (3 1/2 IF) / 2 3/8 Reg MH 229.00
- Internal threadNC 38 (3 1/2 IF)
- External thread2 3/8 Reg
- Diameter, mm.140
- Length, mm.206
- Weight, kg.11,5
Adapter NC 38 (3 1/2 IF) / 2 3/8 Reg MH 229.00
PART NUMBER: MH 229.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter 56x12H/Sp M57xZN MH 220.00
- Internal threadtrapezoidal 56x12 thread
- External threadlock thread Sp. M57x3
- Diameter, mm.76
- Length, mm.400
- Weight, kg.9,5
- PurposeAdapter from BP-76 rod to P-105 (M48) pneumatic hammer manufactured by SOMZ
Adapter 56x12H/Sp M57xZN MH 220.00
PART NUMBER: MH 220.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter 56x12H/72x12H 100.12.00.008
- Internal threadtrapezoidal 56x12 thread
- External threadtape 72-10
- Diameter, mm.76
- Length, mm.330
- Weight, kg.6,5
- PurposeAdapter from BP-76 rod to P-110 and P-130 pneumatic hammers
Adapter 56x12H/72x12H 100.12.00.008
PART NUMBER: 100.12.00.008
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter 72x10V/NC 38 (3 1/2 IF) MH 224.00
- Internal threadtape thread 72x10
- External threadNC 38 (3 1/2 IF)
- Diameter, mm.140
- Length, mm.130
- Weight, kg.9,6
- PurposeAdapter from SBU-89 and BP-89 rods to P-160 pneumatic hammer
Adapter 72x10V/NC 38 (3 1/2 IF)N MH 224.00
PART NUMBER: MH 224.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter 72x10N/NC 38 (3 1/2 IF)N MH 242.00
- Internal threadtape thread 72x10
- External threadNC 38 (3 1/2 IF)
- Diameter, mm.118
- Length, mm.330
- Weight, kg.11,1
- PurposeAdapter from BP-89 rod to P-160 pneumatic hammer
Adapter 72x10N/NC 38 (3 1/2 IF)N MH 242.00
PART NUMBER: MH 242.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter 72x10N/72x10N 100.12.00.009
- Internal threadtape thread 72x10
- External threadtape thread 72x10
- Diameter, mm.89
- Length, mm.324
- Weight, kg.5,9
- PurposeAdapter from BP-89 rod to P-110 and P-130 pneumatic hammers
Adapter 72x10N/72x10N 100.12.00.009
PART NUMBER: 100.12.00.009
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter 72x10V/72x10V MX 247.00
- Internal threadtape thread 72x10
- External threadtape thread 72x10
- Diameter, mm.89
- Length, mm.180
- Weight, kg.4,0
- PurposeAdapter from the SBU-89 rod to the fishing tool for the BP-89 rod
Adapter 72x10V/72x10V MX 247.00
PART NUMBER: MH 247.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter KL Z-50V/72x10N MH 233.00
- Internal threadlock thread Z-50
- External threadtape thread 72x10
- Diameter, mm.76
- Length, mm.170
- Weight, kg.3,0
- PurposeAdapter valve from URB and NKR rods with Z-50 locking thread to P-110 and P-130 pneumatic hammers
Adapter KL Z-50V/72x10N MH 233.00
PART NUMBER: MH 233.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter KL Z-58x3V/72x10N MH 234.00
- Internal threadlock thread Z-58x3
- External threadtape thread 72x10
- Diameter, mm.76
- Length, mm.170
- Weight, kg.2,9
- PurposeAdapter valve from NKR rod with locking thread Z-58x3 to pneumatic hammers P-110 and P-130
Adapter KL Z-58x3V/72x10N MH 234.00
PART NUMBER: MH 234.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameAdapter M70xZN / 3 1/2 Reg MH 235.00
- Internal threadmetric thread M70x3
- External thread3 1/2 Reg
- Diameter, mm.117
- Length, mm.286
- Weight, kg.11,8
- PurposeBTS-150 machine; adapter from the rotator to the rod
Adapter M70xZN / 3 1/2 Reg MH 235.00
PART NUMBER: MH 235.00
Check with the manager for the information about availability and delivery terms after submitting your application
- NameAdapter M70xZN / 3 1/2 Reg MH 238.00
- Internal threadmetric thread M70x3
- External thread3 1/2 Reg
- Diameter, mm.117
- Length, mm.296
- Weight, kg.11,9
- PurposeBTS-150 machine; adapter from the rotator to the rod
Adapter M70xZN / 3 1/2 Reg MH 238.00
PART NUMBER: MH 238.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameNut for gland coupling М48x2LB/З-50Н МH 236.00
- Internal threadmetric M48x2LH (left)
- External threadZ-50
- Diameter, mm.70
- Length, mm.97
- Weight, kg.0,9
- PurposeFor the NKR-63 drill rod
Nut for gland coupling М48x2LB/З-50N МH 236.00
PART NUMBER: MH 236.00
Check with the manager for the information about availability and delivery terms after submitting your application
