Fishing taps for machines of the BP-100 type, diameter of the rod 76 mm.
Brief specifications
- Image
- Range of internal diameters of captured elements, mm.18...24
- Borehole diameter, not less than, mm.82
- Length of fishing thread, mm.80
- Connecting threadtrapezoidal 56x12
- Length, mm.230
- Weight, kg.2,9
Fishing tap No. 5 MH 53.05 assembled with adapter MH 50.06
PART NUMBER: МH 53.05
Check with the manager for the information about availability and delivery terms after submitting your application
- Range of internal diameters of captured elements, mm.21...27
- Borehole diameter, not less than, mm.82
- Length of fishing thread, mm.85
- Connecting threadtrapezoidal 56x12
- Length, mm.230
- Weight, kg.2,7
Fishing tap No. 1 MH 53.01 assembled with adapter MH 50.06
PART NUMBER: МH 53.01
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Range of internal diameters of captured elements, mm.29...35
- Borehole diameter, not less than, mm.82
- Length of fishing thread, mm.85
- Connecting threadtrapezoidal 56x12
- Length, mm.230
- Weight, kg.3,0
Fishing tap No. 2 MH 53.02 assembled with adapter MH 50.06
PART NUMBER: МH 53.02
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Range of internal diameters of captured elements, mm.49...53
- Borehole diameter, not less than, mm.82
- Length of fishing thread, mm.74
- Connecting threadtrapezoidal 56x12
- Length, mm.211
- Weight, kg.3,8
Fishing tap No. 3 MH 50.03
PART NUMBER: МH 50.03
Check with the manager for the information about availability and delivery terms after submitting your application
- Range of internal diameters of captured elements, mm.63...69
- Borehole diameter, not less than, mm.82
- Length of fishing thread, mm.95
- Connecting threadtrapezoidal 56x12
- Length, mm.232
- Weight, kg.5,4
Fishing tap No. 4 MH 50.04
PART NUMBER: МH 50.04
Check with the manager for the information about availability and delivery terms after submitting your application
