Fishing sockets
Brief specifications
- Image
- Range of diameters of captured elements, mm.58...63
- Borehole diameter, not less than, mm.208
- Length of fishing thread, mm.75
- Connecting threadZ-50
- Length, mm.308
- Weight, kg.7,0
Overshot for drilling rods NKR-63 type MH 360.50
PART NUMBER: MH 360.50
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Range of diameters of captured elements, mm.58...63
- Borehole diameter, not less than, mm.102
- Length of fishing thread, mm.75
- Connecting threadZ-50
- Length, mm.308
- Weight, kg.5,2
Overshot for drilling rods NKR-63 type MH 360.10
PART NUMBER: MH 360.10
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Range of diameters of captured elements, mm.60...52
- Borehole diameter, not less than, mm.102
- Length of fishing thread, mm.91
- Connecting threadZ-58x3
- Length, mm.226
- Weight, kg.4,3
Overshot for drilling rods NKR-63 type MH 360.21
PART NUMBER: MH 360.21
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Range of diameters of captured elements, mm.70...78
- Borehole diameter, not less than, mm.102
- Length of fishing thread, mm.115
- Connecting threadtrapezoidal 56x12
- Length, mm.272
- Weight, kg.6,8
Overshot for drilling rods BP-76 type MH 50.07
PART NUMBER: MH 50.07
Check with the manager for the information about availability and delivery terms after submitting your application
- Range of diameters of captured elements, mm.86...91
- Well diameter, not less than, mm.102
- Length of fishing thread, mm.44
- Connecting threadtape thread 72x10
- Length, mm.230
- Weight, kg.5,5
Overshot for drilling rods BP-89 type MH 53.09
PART NUMBER: MH 53.09
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Range of diameters of captured elements, mm.60...52
- Borehole diameter, not less than, mm.102
- Length of fishing thread, mm.91
- Connecting threadtrapezoidal 56x12
- Length, mm.226
- Weight, kg.4,6
Overshot for drilling rods KNSH-105 BR (BP-76 type) MH 360.31
PART NUMBER: MH 360.31
Check with the manager for the information about availability and delivery terms after submitting your application
