Drill bits QL60N valveless
Brief specifications
- Name KNSH-165 QL60N MH 4010.00-80
- Nominal drill bit diameter, mm 165
- Gauge angle, deg. 35
- Carbide (outer) hemispherical 10 × Ø16
- Carbide (front) semi-ballistics 10 × Ø16
- Flushing holes 2
- Length L, mm 350,5
- Weight, kg 24,1
KNSH-165 QL60N MH 4010.00-80
PART NUMBER: MH 4010.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-165 QL60N MH 517.00-80
- Nominal drill bit diameter, mm 165
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø16
- Carbide (front) Hemispherical 10 × Ø16
- Flushing holes 2
- Length L, mm 349
- Weight, kg 24.4
KNSH-165 QL60N MH 517.00-80
PART NUMBER: MH 517.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-171 QL60N MH 513.00-80
- Nominal drill bit diameter, mm 171
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø19
- Carbide (front) Hemispherical 9 × Ø16
- Flushing holes 2
- Length L, mm 353
- Weight, kg 26.3
KNSH-171 QL60N MH 513.00-80
PART NUMBER: MH 513.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-171 QL60N MH 527.00-80
- Nominal drill bit diameter, mm 171
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø16
- Carbide (front) Hemispherical 9 × Ø16
- Flushing holes 2
- Length L, mm 353
- Weight, kg 26.1
KNSH-171 QL60N MH 527.00-80
PART NUMBER: MH 527.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-178 QL60N MH 4011.00-80
- Nominal drill bit diameter, mm 178
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø19
- Carbide (front) Hemispherical 12 × Ø16
- Flushing holes 2
- Length L, mm 350
- Weight, kg 26
KNSH-178 QL60N MH 4011.00-80
PART NUMBER: MH 4011.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-186 QL60N MH 4020.00-80
- Nominal drill bit diameter, mm 186
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø19
- Carbide (front) Hemispherical 12 × Ø16
- Flushing holes 2
- Length L, mm 350
- Weight, kg 27,4
KNSH-186 QL60N MH 4020.00-80
PART NUMBER: MH 4020.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-203 QL60N MH 537.00-80
- Nominal drill bit diameter, mm 203
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø19
- Carbide (front) Hemispherical 17 × Ø16
- Flushing holes 2
- Length L, mm 353
- Weight, kg 32.4
KNSH-203 QL60N MH 537.00-80
PART NUMBER: MH 537.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-203 QL60N MH 538.00-80
- Nominal drill bit diameter, mm 203
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø16
- Carbide (front) Hemispherical 17 × Ø16
- Flushing holes 2
- Length L, mm 353
- Weight, kg 31.9
KNSH-203 QL60N MH 538.00-80
PART NUMBER: MH 538.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-203 QL60N MH 596.00-80 (gauge reinforcement)
- Nominal drill bit diameter, mm 203
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø19
- Carbide (front) Hemispherical 17 × Ø16
- Flushing holes 2
- Length L, mm 361
- Weight, kg 32.4
KNSH-203 QL60N MH 596.00-80 (gauge reinforcement)
PART NUMBER: MH 596.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-171 QL60N MH 877.00-80
- Nominal drill bit diameter, mm 171
- Gauge angle, deg. 35 15
- Carbide (outer) Hemispherical 16 × Ø18
- Carbide (front) Hemispherical 5 × Ø18
- Flushing holes 2
- Length L, mm 353
- Weight, kg 26
KNSH-171 QL60N MH 877.00-80
PART NUMBER: MH 877.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-171 QL60N MH 879.00-80
- Nominal drill bit diameter, mm 171
- Gauge angle, deg. 35 15
- Carbide (outer) Hemispherical 16 × Ø19
- Carbide (front) Hemispherical 5 × Ø19
- Flushing holes 2
- Length L, mm 354
- Weight, kg 25,4
KNSH-171 QL60N MH 879.00-80
PART NUMBER: MH 879.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-190 QL60N MH 4005.00-80
- Nominal drill bit diameter, mm 190
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø19
- Carbide (front) Hemispherical 12 × Ø16
- Flushing holes 2
- Length L, mm 350
- Weight, kg 27,4
KNSH-190 QL60N MH 4005.00-80
PART NUMBER: MH 4005.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-203 QL60N MH 1431.00-80
- Nominal drill bit diameter, mm 203
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø19
- Carbide (front) Hemispherical 12 × Ø16
- Flushing holes 2
- Length L, mm 353
- Weight, kg 28,7
KNSH-203 QL60N MH 1431.00-80
PART NUMBER: MH 1431.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-203 QL60N MH 1428.00-80 (gauge reinforcement)
- Nominal drill bit diameter, mm 203
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 18 × Ø19
- Carbide (front) Hemispherical 9 × Ø16
- Flushing holes 2
- Length L, mm 353
- Weight, kg 32,4
KNSH-203 QL60N MH 1428.00-80
PART NUMBER: MH 1428.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-171 QL60N MH 518.00-80
- Nominal drill bit diameter, mm 171
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø19
- Carbide (front) Hemispherical 9 × Ø16
- Flushing holes 2
- Length L, mm 350
- Weight, kg 25,1
KNSH-171 QL60N MH 4008.00-80
PART NUMBER: MH 4008.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-165 QL60N MH 884.00-80
- Nominal drill bit diameter, mm 165
- Gauge angle, deg. 40 25
- Carbide (outer) Hemispherical 15 × Ø18
- Carbide (front) Hemispherical 5 × Ø18
- Flushing holes 3
- Length L, mm 345
- Weight, kg 50
KNSH-165 QL60N MH 884.00-80
PART NUMBER: MH 884.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-165 QL60N MH 891.00-80
- Nominal drill bit diameter, mm 165
- Gauge angle, deg. 40 25
- Carbide (outer) Hemispherical 12 × Ø22
- Carbide (front) Hemispherical 3 × Ø22
- Flushing holes 3
- Length L, mm 345
- Weight, kg 50
KNSH-165 QL60N MH 891.00-80
PART NUMBER: MH 891.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-171 QL60N MH 883.00-80
- Nominal drill bit diameter, mm 171
- Gauge angle, deg. 40 25
- Carbide (outer) Hemispherical 11 × Ø18
- Carbide (front) Hemispherical 9 × Ø18
- Flushing holes 3
- Length L, mm 353
- Weight, kg 26
KNSH-171 QL60N MH 883.00-80
PART NUMBER: MH 883.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-165 QL60N MH 1405.00-80
- Nominal drill bit diameter, mm 165
- Gauge angle, deg. 40 25
- Carbide (outer) Hemispherical 10 × Ø19
- Carbide (front) Hemispherical 9 × Ø16
- Flushing holes 2
- Length L, mm 353
- Weight, kg 26
KNSH-165 QL60N MH 1405.00-80
PART NUMBER: MH 1405.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-165 QL60N MH 1401.00-80 SPEEDBIT
- Nominal drill bit diameter, mm 165
- Gauge angle, deg. 40 25
- Carbide (outer) Semi-ballistic 15 × Ø16
- Carbide (front) Semi-ballistic 7 × Ø16
- Flushing holes 3
- Length L, mm 352
- Weight, kg 25
KNSH-165 QL60N MH 1401.00-80 SPEEDBIT
PART NUMBER: MH 1401.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-165 QL60N MH 4010.00-80 SPEEDBIT
- Nominal drill bit diameter, mm 165
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø16
- Carbide (front) Semi-ballistic 10 × Ø16
- Flushing holes 2
- Length L, mm 350,5
- Weight, kg 24,1
KNSH-165 QL60N MH 4010.00-80 SPEEDBIT
PART NUMBER: MH 4010.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-178 QL60N MH 529.00-80
- Nominal drill bit diameter, mm 178
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 9 × Ø18
- Carbide (front) Hemispherical 9 × Ø18
- Flushing holes 3
- Length L, mm 354
- Weight, kg 26.2
KNSH-178 QL60N MH 529.00-80
PART NUMBER: MH 529.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-165 QL60N MH 519.00-80
- Nominal drill bit diameter, mm 165
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 9 × Ø19
- Carbide (front) Hemispherical 9 × Ø16
- Flushing holes 3
- Length L, mm 353
- Weight, kg 25.4
KNSH-165 QL60N MH 519.00-80
PART NUMBER: MH 519.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-171 QL60N MH 518.00-80
- Nominal drill bit diameter, mm 171
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 9 × Ø18
- Carbide (front) Hemispherical 9 × Ø18
- Flushing holes 3
- Length L, mm 354
- Weight, kg 26,3
KNSH-171 QL60N MH 518.00-80
PART NUMBER: MH 518.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-203 QL60N MH 539.00-80 (gauge reinforcement)
- Nominal drill bit diameter, mm 203
- Gauge angle, deg. 40
- Carbide (outer) Hemispherical 9 × Ø19
- Carbide (front) Hemispherical 6 × Ø19, hemispherical 3 × Ø18
- Flushing holes 2
- Length L, mm 362
- Weight, kg 32,2
KNSH-203 QL60N MH 539.00-80 (gauge reinforcement)
PART NUMBER: MH 539.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-203 QL60N MH 1429.00-80 (gauge reinforcement)
- Nominal drill bit diameter, mm 203
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 18 × Ø19
- Carbide (front) Hemispherical 9 × Ø16
- Flushing holes 2
- Length L, mm 353
- Weight, kg 30,5
KNSH-203 QL60N MH 1429.00-80
PART NUMBER: MH 1429.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-203 QL60N MH 882.00-80 (gauge reinforcement)
- Nominal drill bit diameter, mm 203
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 12 × Ø19
- Carbide (front) Hemispherical 18 × Ø18
- Flushing holes 2
- Length L, mm 353
- Weight, kg 49,6
KNSH-203 QL60N MH 882.00-80
PART NUMBER: MH 882.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
