Drill bits М60
Brief specifications
- Image
- Name KNSH-171 M60 MH 1432.00
- Nominal drill bit diameter, mm 171
- Gauge angle, deg. 25 / 40
- Carbide (outer) Hemispherical 9 × Ø18
- Carbide (front) Hemispherical 11 × Ø18
- Flushing holes 3
- Length L, mm 330,5
- Weight, kg 22,8
KNSH-171 M60 MH 1432.00
PART NUMBER: MH 1432.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-172 M60 MH 542.00
- Nominal drill bit diameter, mm 172
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 9 × Ø18
- Carbide (front) Hemispherical 8 × Ø18
- Flushing holes 3
- Length L, mm 330.5
- Weight, kg 23.5
KNSH-172 M60 MH 542.00
PART NUMBER: MH 542.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-165 M60 MH 567.00
- Nominal drill bit diameter, mm 165
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 9 × Ø19
- Carbide (front) Hemispherical 9 × Ø16
- Flushing holes 3
- Length L, mm 330
- Weight, kg 23.6
KNSH-165 M60 MH 567.00
PART NUMBER: MH 567.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-172 M60 MH 544.00
- Nominal drill bit diameter, mm 172
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 9 × Ø18
- Carbide (front) Hemispherical 9 × Ø18
- Flushing holes 3
- Length L, mm 330,5
- Weight, kg 23,2
KNSH-172 M60 MH 4004.00
PART NUMBER: MH 4004.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-178 M60 MH 540.00
- Nominal drill bit diameter, mm 178
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 9 × Ø18
- Carbide (front) Hemispherical 9 × Ø18
- Flushing holes 3
- Length L, mm 330.5
- Weight, kg 24.5
KNSH-178 M60 MH 540.00
PART NUMBER: MH 540.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-203 M60 MH 869.00
- Nominal drill bit diameter, mm 203
- Gauge angle, deg. 40
- Carbide (outer) Hemispherical 9 × Ø18
- Carbide (front) Hemispherical 12 × Ø18
- Flushing holes 3
- Length L, mm 339
- Weight, kg 30
KNSH-203 M60 MH 869.00
PART NUMBER: MH 869.00
Check with the manager for the information about availability and delivery terms after submitting your application
