Drill bits DHD340N
Brief specifications
- Image
- Name KNSH-115 DHD340N MH 573.00
- Nominal drill bit diameter, mm 115
- Gauge angle, deg. 40 12
- Carbide (outer) Hemispherical 7 × Ø16
- Carbide (front) Semi-ballistic 6 × Ø14
- Flushing holes 2
- Length L, mm 292.5
- Weight, kg 9.5
KNSH-115 DHD340N MH 573.00
PART NUMBER: MH 573.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-130 DHD340N MH 885.00
- Nominal drill bit diameter, mm 130
- Gauge angle, deg. 40 20
- Carbide (outer) Hemispherical 7 × Ø16
- Carbide (front) Conical 7 × Ø14
- Flushing holes 2
- Length L, mm 304
- Weight, kg 10.6
KNSH-130 DHD340N MH 885.00
PART NUMBER: MH 885.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-105 DHD340N MH 528.00-80
- Nominal drill bit diameter, mm 105
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 8 × Ø14
- Carbide (front) Hemispherical 7 × Ø13
- Flushing holes 2
- Length L, mm 301
- Weight, kg 8,9
KNSH-105 DHD340N MH 528.00-80
PART NUMBER: MH 528.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-110 DHD340N MH 525.00-80
- Nominal drill bit diameter, mm 110
- Gauge angle, deg. 35
- Carbide (outer) hemisphere 8 × Ø14
- Carbide (front) hemisphere 7 × Ø13
- Flushing holes 2
- Length L, mm 301
- Weight, kg 9,4
KNSH-110 DHD340N MH 525.00-80
PART NUMBER: MH 525.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-110 DHD340N MH 563.00-80
- Nominal drill bit diameter, mm 110
- Gauge angle, deg. 35
- Carbide (outer) hemisphere 8 × Ø16
- Carbide (front) hemisphere 6 × Ø16
- Flushing holes 2
- Length L, mm 302,5
- Weight, kg 9,5
KNSH-110 DHD340N MH 563.00-80
PART NUMBER: MH 563.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-110 DHD340N MH 578.00-80
- Nominal drill bit diameter, mm 110
- Gauge angle, deg. 35
- Carbide (outer) Semi-ballistic 8 × Ø16
- Carbide (front) Semi-ballistic 6 × Ø16
- Flushing holes 2
- Length L, mm 302,5
- Weight, kg 9,3
KNSH-110 DHD340N MH 578.00-80
PART NUMBER: MH 578.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-115 DHD340N MH 4009.00-80
- Nominal drill bit diameter, mm 115
- Gauge angle, deg. 35
- Carbide (outer) hemisphere 8 × Ø14
- Carbide (front) hemisphere 4 × Ø14
- Flushing holes 2
- Length L, mm 288,5
- Weight, kg 8,4
KNSH-115 DHD340N MH 4009.00-80
PART NUMBER: MH 4009.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-120 DHD340N MH 1407.00-80
- Nominal drill bit diameter, mm 120
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 8 × Ø14
- Carbide (front) Hemispherical 8 × Ø14
- Flushing holes 2
- Length L, mm 301,5
- Weight, kg 10
KNSH-120 DHD340N MH 1407.00-80
PART NUMBER: MH 1407.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-130 DHD340N MH 4001.00-80
- Nominal drill bit diameter, mm 130
- Gauge angle, deg. 35
- Carbide (outer) hemisphere 8 × Ø16
- Carbide (front) hemisphere 7 × Ø14
- Flushing holes 2
- Length L, mm 288,7
- Weight, kg 9,3
KNSH-130 DHD340N MH 4001.00-80
PART NUMBER: MH 4001.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-115 DHD340N MH 572.00-80 SPEEDBIT
- Nominal drill bit diameter, mm 115
- Gauge angle, deg. 40
- Carbide (outer) Hemispherical 7 × Ø16
- Carbide (front) Semi-ballistic 4 × Ø14 2 × Ø14
- Flushing holes 2
- Length L, mm 301
- Weight, kg 9.2
KNSH-115 DHD340N MH 572.00-80 SPEEDBIT
PART NUMBER: MH 572.00-80 SPEEDBIT
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-110 DHD340N MH 4015.00-80
- Nominal drill bit diameter, mm 110
- Gauge angle, deg. 35
- Carbide (outer) Semi-ballistic 8 × Ø16
- Carbide (front) Semi-ballistic 6 × Ø16
- Flushing holes 2
- Length L, mm 288,7
- Weight, kg 8,2
KNSH-110 DHD340N MH 4015.00-80
PART NUMBER: MH 4015.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-110 DHD340N MH 4014.00-80
- Nominal drill bit diameter, mm 110
- Gauge angle, deg. 35
- Carbide (outer) hemisphere 8 × Ø16
- Carbide (front) hemisphere 6 × Ø16
- Flushing holes 2
- Length L, mm 289
- Weight, kg 8,4
KNSH-110 DHD340N MH 4014.00-80
PART NUMBER: MH 4014.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-110 DHD340N MH 4016.00-80
- Nominal drill bit diameter, mm 110
- Gauge angle, deg. 35
- Carbide (outer) semiballistics 8 × Ø16
- Carbide (front) semiballistics 6 × Ø16
- Flushing holes 2
- Length L, mm 289
- Weight, kg 8,4
KNSH-110 DHD340N MH 4016.00-80
PART NUMBER: MH 4016.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-110 DHD340N MH 4019.00
- Nominal drill bit diameter, mm 110
- Gauge angle, deg. 40
- Carbide (outer) semiballistics 8 × Ø16
- Carbide (front) semiballistics 6 × Ø16
- Flushing holes 2
- Length L, mm 289
- Weight, kg 8,5
KNSH-110 DHD340N MH 4019.00
PART NUMBER: MH 4019.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-130 DHD340N MH 4003.00-80 SPEEDBIT
- Nominal drill bit diameter, mm 130
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 8 × Ø16
- Carbide (front) Semi-ballistic 7 × Ø14
- Flushing holes 2
- Length L, mm 288,7
- Weight, kg 9,3
KNSH-130 DHD340N MH 4003.00-80 SPEEDBIT
PART NUMBER: MH 4003.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-130 DHD340N MH 881.00-80
- Nominal drill bit diameter, mm 130
- Gauge angle, deg. 40 / 20
- Carbide (outer) ballistic 15 × Ø12
- Carbide (front) ballistic 7 × Ø12
- Flushing holes 3
- Length L, mm 303
- Weight, kg 9,5
KNSH-130 DHD340N MH 881.00-80
PART NUMBER: MH 881.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-130 DHD340N MH 4002.00-80
- Nominal drill bit diameter, mm 130
- Gauge angle, deg. 40 / 20
- Carbide (outer) conical 9 × Ø13
- Carbide (front) conical 11 × Ø13
- Flushing holes 3
- Length L, mm 290,5
- Weight, kg 9,2
KNSH-130 DHD340N MH 4002.00-80
PART NUMBER: MH 4002.00-80
Check with the manager for the information about availability and delivery terms after submitting your application
